    Villa Home Off Grid DC48V Hybrid Solar Pv System

    Ask Lasest Price
    Brand Name : Fenigal
    Model Number : PV Solar System
    Certification : ISO, CE
    Price : Negotiate
    Payment Terms : T/T, Western Union
    Supply Ability : depend on quantity
    Delivery Time : 5-8 working days bulk order negotiate
    • Product Details
    • Company Profile

    Villa Home Off Grid DC48V Hybrid Solar Pv System

    The Applications of the of grid system :
    Solar power is an environmental friendly safe energy with abundant supply. Installing a on grid residential solar power system is a good way to meet the rising renewable energy portfolio standards.


    With various level of governments' financial support for solar power system installation and feed -in-tariff­ for purchasing solar power feed into the grid, solar power system investment has become a risk-free financial product with a very attractive rate of return.


    Small systems such as this 2000 Watt microinverter kit are great entry level packages to get you going with solar. The seven 310W modules don't take up much roof space, but the energy they produce can offset small and medium size loads like lighting, television and your kitchen appliances.

    The 175-375kWh generated by these systems is great for a person who is already a conservative user of electricity. The average American uses 920kWh per month. Based on that average, this system could provide 20-41%. If you're a below average consumer, a small 2000W system like this might be all you need to get started then expand your system later.


    Technical Data


    Off grid solar power system
    SystemSolar panel rated output power: 2000W
    Basic InformationSuitable for daily power consumption : >50.4KWH
     Allowable max loads power : 8KW(=11.4KVA)SP-8kw

      Full set:
      Total volume:3.5CBM
      Total weight:1300KG
    Solar panelFS350W mono solar panel(poly optional)QTY
     Vmp:38.39V Voc:47.13V Imp 9.37A24pcs
    (Mono) ( poly)Size : 1956*992*40mm
     25 years life time (CE TUV)
     Coated steel Glass:3.2mm Tem pered
     Efficiency performance :25 years 80 % 20 year 85% 10 years 90% TANFON advantage:
     Connect way:each 4 pcs in series Training team and installation service
    PV Array CombinerModel:H6T-96v Multiple PV strings inputsQTY
    and controller, Prevent hot spot effect1pc
    Reliable thunderstorm& surge protection
    Product Size:400*425*145mm
    Solar ControllerMPPT controller model:96V/60AQTY
    Charging efficiency; 90%-95%,1pc
    charging mode, intelligent control.,
    various protection functions
    Pure sine wave InverterInverter:8KW96VDCQTY
    110V/120V/220V/230V/240VAC output,1pc
    City power and generator charger build in Overload, overcharge, over-discharge protection
    Fuji brand IGBT material
    Gel BatteryCapacity:12V/150AHQTY
    full sealed Solar power gel battery,16pcs
    Service life:6-8 years ,
    Size:483*170*219mm
    Connect way: 8pcs battery in series is each string,
    2 strings connect to solar hybrid inverter
    panel rackSlope Rooftop or Flat rooftopQTY
    wind load:55m/s,snow load:1.5kn/m21set
    structure:Anodized Aluminum+stainless steel, Angle adjustable
    (other type of rack can be customized as per client's requirement )
    Cables1) 14pcs 16mm2*35CM battery cableQTY
    4pcs 16mm2*1M battery cable1set
    2)4mm2 PV cable 200M
    3)terminals and MC4+2P63A Battery switch
    Home system Load reference
    Load nameLoad's wattQtyTotal watt
    lights11W12132This exemple is just for reference. But Your load can be less than 8kw
    Fan80W4320
    Computer(LCD display)150W2300
    printer250W1250
    Fax machine150W1150
    refrigerator(200L)120W3360
    Washing machine300W1300
    Microwave1500W11500
    Electric cooker300W2600
    Air conditioner(1.5HP)1125W33375
    Satellite TV receiver/VCD25W125
    Color TV(32 inch)150W2300
    Water pump200W1200
    Total7812
